XIXIN !s NINETEEN INCH
MURALIS/ARCA
ARCA RANGE
THE ARCA IS AN ECONOMY RANGE OF 19” FLOOR STANDING ENCLOSURES FROM XIXIN DEVELOPED IN RESPONSE TO CUSTOMER DEMAND FOR A COST EFFECTIVE RACKING ENCLOSURE.
IT IS SUITABLE FOR A WIDE RANGE OF INSTALLATIONS INCLUDING AUDIO/VISUAL, CCTV AND SECURITY.
THE BASIC ENCLOSURE CAN BE ADAPTED TO CUSTOMER NEEDS BY THE ADDITION OF VARIOUS FACTORY FITTED OPTIONS.
HEIGHTS 12, 15, 18, 21, 24, 27, 30, 33, 36, 39, and 42U
WIDTH 600MM
DEPTHS 300, 400, 500 & 600MM
OPTIONS
REAR 19” RACKING
Extra racking can be fitted at the rear of the cabinet to support shelves and equipment.
FRONT DOORS
The Arca can be fitted with a glazed acrylic door or a steel door at the front, both of which are lockable.
REAR PANEL OPTION
A rear panel can be ordered to close off the rear of the unit. When a rear panel is ordered, a 3U fan/cable entry panel can be mounted below the rear panel, fitted with either 2 fans for forced ventilation, a gland plate or brush strip for cable entry.
SPECIAL ‘NO DOOR’ FRONT FRAME
When the Arca is ordered without a front door a special front frame can be ordered to give a more streamlined appearance. In conjunction with this a trim strip in the same or a contrasting colour can be ordered. If a front door is to be fitted at a later date, the standard door frame will be supplied.
STANDARD BUILD
The standard cabinet is supplied complete with fully adjustable front 19” racking, a fixed top, removable side panels, a gland plate base, ventilation slots at the top and base of each side and adjustable feet.
MURALIS RANGE
STANDARD BUILD
The standard cabinet is supplied complete with fully adjustable front 19” racking, gland plate entry top and base, fixed side panels, ventilation slots at the top and base of each side and a wall mounting bracket.
OPTIONS
REAR 19” RACKING
Extra racking can be fitted at the rear of the cabinet to support shelves and equipment.
FRONT DOORS
The Muralis can be fitted with a glazed acrylic door or a steel door, both of which are lockable.
WALL MOUNTING FRAME
The Muralis is also available as a two section cabinet by adding a 100mm deep wall frame, This allows the front section to swing out whilst the rear frame remains fixed to the wall. This enables easy access to equipment no matter how restricted the space. The wall mounting frame adds 100mm to the overall depth of the unit
XIXIN LTD Bilton Way Luton Beds LU1 1UU
TEL: 01582 400340. FAX: 01582 481498.
EMAIL: sales@xixin.co.uk WEB: xixin.co.uk
HEIGHTS 6, 9, 12, 15, 18, 21, 24, 27,U
WIDTH 600MM
DEPTHS 300, 400, 500 & 600MM
THE MURALIS IS A RANGE OF WALL MOUNTING ENCLOSURES DESIGNED TO MAKE INSTALLATION EASY, THEREBY REDUCING LABOUR COSTS. ITS STYLING MATCHES THAT OF THE ARCA RANGE.
ITS LIGHTWEIGHT CONSTRUCTION IS IDEAL FOR AUDIO VISUAL, CCTV AND SECURITY INSTALLATIONS WHERE FLOOR SPACE IS AT A PREMIUM.
